chipKIT Lesson: LCD HD44780

April 18th, 2012  Posted at   Lesson ChipKIT
arrow   |   3 Commentsarrow

LCD HD44780 adalah character LCD yang biasa digunakan. Interface LCD HD44780 dengan PIC boleh rujuk PIC Lesson: LCD HD44780.

Interface LCD HD44780 ini menggunakan enam pin. Sambungan pin nya adalah di bawah

  • RS = 8
  • EN = 9
  • D4 = 10
  • D5 = 11
  • D6 = 12
  • D7 = 13

Berikut adalah videonya.
