PIC Project: Dot Matrix Signboard (32X16)
Project Dot Matrix Signboard 32X16 menggunakan satu 32X16 Dot Matrix Module daripada Sure Electronics.
Skematiknya adalah seperti berikut.
| No | Component | Label | Unit |
|---|---|---|---|
| 1 | Box Header 16 Ways Straight | SURE | 1 |
| 2 | Buzzer-PCB Mount | Buzzer | 1 |
| 3 | Capacitor Ceramic 0.1uF | C5 | 1 |
| 4 | Capacitor Electrolytic 10uF | C1-C4 | 4 |
| 5 | Cell Battery CR2032 | Battery 3V | 1 |
| 6 | Cell Battery Holder | Battery 3V | 1 |
| 7 | Crystal RTC 32.768kHz | XTAL | 1 |
| 8 | DC Jack Female | DC Jack Female | 1 |
| 9 | Diode 1N4001 | D1 | 1 |
| 10 | IC DS1307 DIP | DS1307 | 1 |
| 11 | IC PIC16F1938 DIP | PIC16F1938 | 1 |
| 12 | IC Socket 28pin | PIC16F1938 | 1 |
| 13 | IC Socket 8pin | DS1307 | 1 |
| 14 | P4 32X16 3216 RG Dual Color LED Dot Matrix Unit Display Board | SURE | 1 |
| 15 | PCB 1 layer | PCB | 1 |
| 16 | PCB Connector Header (Right) 3 Ways | PWR_1 | 1 |
| 17 | PCB Connector Housing 3 Ways | PWR_1 | 1 |
| 18 | PCB Stand (screw nut) | PCB Stand | 4 |
| 19 | Push Button 4 pin 6x6x1 | PB1-PB4 | 4 |
| 20 | Resistor 0.25W 1K | R1-R6 | 6 |
| 21 | Right Angle Pin Header (Male) | ICSP | 1 |
| 22 | Slide Switch | S1 | 1 |
| 23 | Terminal Block 2 Way | PWR | 1 |
| 24 | Terminal Pin | PWR_1 | 3 |
| 25 | TIP2955 | TIP2955 | 1 |
| 26 | Voltage Regulator 5V TO220 | 7805 | 1 |
Harga projek Dot Matrix Signboard (32×16) adalah RM540 tidak termasuk bantuan teknikal. Di bawah adalah cara projek ini berfungsi.
kalo contoh sye beli projek ni saye dpt smua ke mklumat pasal projek nie??
Saya bg hardware dan software (Schematic, PCB Design dan coding)
Assalamualaikum, mas klo led signboard kita kontrol menggunakan ATmega 8535 mampu tidak atmega 8535? ada tutorial/refrensi untuk belajar tentang signboard led tersebut?
terimakasih..
waalaikumussalam, saya tidak pernah gunakan ATmega, tapi Dot Matrix ini boleh interface dgn apa2 MCU juga.
Dear Sir,
Pls send me complete information like diagram and program if possible.
Thanks in advance.
Best regards
rajeev, program not for free.
HI SHAHRULIZAM I AM NOOR FROM EGYPT I NEED YOUR HELP TO MAKE A LED DOT MATRIX FROM A TO Z PLEASE I WANT IT AT MY WORK ,, THANKS
Sorry, Noor. I don’t have many time to assists individual person. You must spend your time, learn yourself.
