PIC Project: Temperature Control


PIC Temperature Control

Temperature Control adalah projek untuk mengawal suhu persekitaran seperti dalam sebuah bilik. Menggunakan sensor suhu LM35 untuk membaca suhu persekitaran. Sekiranya suhu panas melebihi suhu yang disetkan, kipas akan berpusing untuk menyejukkan persekitaran. Sekiranya suhu sejuk, kipas akan berhenti berpusing. Projek ini boleh disetkan had suhu dan kelajuan kipas.

Skematiknya adalah seperti berikut.

Schematic Temperature Control

PCB komponen layout nya adalah seperti berikut.

PCB Temperature Control

Senarai komponen projek PIC Temperature Control seperti berikut.
No Component Label Unit
1 031 PCB PIC LCD Monitoring (100mm X 88mm) PCB 1
2 031 PCB PIC LCD Monitoring (100mm X 88mm) PCB 1
3 Capacitor Ceramic 0.1uF C5 1
4 Capacitor Electrolytic 10uF C1-C2 2
5 DC Bulb 12V 1.5W OUT_1-OUT_4 2
6 DC Fan 12V 0.3A 80mmx80mm OUT_1-OUT_4 2
7 DC Jack Female DC Jack Female 1
8 Diode 1N4001 D1 1
9 IC PIC16F1939 DIP PIC16F1939 1
10 IC Socket 40pin PIC16F1939 1
11 LCD 20X4 LCD 1
12 Mosfet IRF540 TO220 Q2-Q5 4
13 PCB Connector Header (Right) 3 Ways IN_1 1
14 PCB Connector Housing 3 Ways IN_1 1
15 PCB Stand (screw nut) PCB Stand 6
16 Push Button 4 pin 6x6x1 PB1-PB4 4
17 Resistor 0.25W 1K R18-R21 4
18 Resistor 0.25W 1K R12-R15 4
19 Resistor 0.25W 1K/4.7K R4 1
20 Resistor 0.25W 330 R1 1
21 Right Angle Pin Header (Male) ICSP 1
22 Sensor LM35 IN_1 1
23 Slide Switch S1 1
24 Terminal Block 2 Way OUT_1-OUT_4 4
25 Terminal Block 2 Way PWR 1
26 Terminal Pin IN_1 3
27 Transistor 2N2222 Q1 1
28 Voltage Regulator 5V TO220 7805 1

Harga projek PIC Temperature Control adalah RM580 tidak termasuk bantuan teknikal. Di bawah adalah cara projek ini berfungsi.
