VB Project: Fingerprint Attendance & Access System with GSM
Fingerprint Attendance & Access System adalah projek Fingerprint Attendance System with GSM yang juga mempunyai fungsi Fingerprint Door Access.
Skematiknya adalah seperti berikut.
PCB komponen layout nya adalah seperti berikut.
| No | Component | Label | Unit |
|---|---|---|---|
| 1 | 072 PCB PIC Attendance System (119mm X 118mm) | PCB | 1 |
| 2 | Bell Switch | IN | 1 |
| 3 | Buzzer-PCB Mount | Buzzer | 1 |
| 4 | Capacitor Ceramic 0.1uF | C5 | 1 |
| 5 | Capacitor Electrolytic 10uF | C1-C2 | 2 |
| 6 | Cell Battery CR2032 | Battery 3V | 1 |
| 7 | Cell Battery Holder | Battery 3V | 1 |
| 8 | Crystal RTC 32.768kHz | XTAL2 | 1 |
| 9 | DC Jack Female | DC Jack Female | 1 |
| 10 | Diode 1N4001 | D1 | 1 |
| 11 | Fingerprint Sensor FPM10A | UART_1 | 1 |
| 12 | GSM SIM900A | UART_2 | 1 |
| 13 | IC DS1307 DIP | DS1307 | 1 |
| 14 | IC PIC18F46K22 DIP | PIC18F46K22 | 1 |
| 15 | IC Socket 40pin | PIC18F46K22 | 1 |
| 16 | IC Socket 8pin | DS1307 | 1 |
| 17 | Keypad 4X4 | Keypad | 1 |
| 18 | LCD 16X2 | LCD | 1 |
| 19 | Magnetic Door Lock 80mm | OUT | 1 |
| 20 | Mosfet IRF540 TO220 | Q2 | 1 |
| 21 | PCB Connector Header (Straight) 3 Ways | PWR_1 | 1 |
| 22 | PCB Connector Header (Straight) 3 Ways | UART_1 | 1 |
| 23 | PCB Connector Header (Straight) 3 Ways | PWR_12 | 1 |
| 24 | PCB Connector Header (Straight) 3 Ways | UART_2 | 1 |
| 25 | PCB Connector Housing 3 Ways | PWR_1 | 1 |
| 26 | PCB Connector Housing 3 Ways | UART_1 | 1 |
| 27 | PCB Connector Housing 3 Ways | UART_2 | 1 |
| 28 | PCB Connector Housing 3 Ways | PWR_2 | 1 |
| 29 | PCB Stand (screw nut) | PCB Stand | 8 |
| 30 | Resistor 0.25W 10K | R3-R6 | 4 |
| 31 | Resistor 0.25W 1K | R14, R16 | 2 |
| 32 | Resistor 0.25W 1K | R12-R13 | 2 |
| 33 | Resistor 0.25W 1K/4.7K | R9 | 1 |
| 34 | Resistor 0.25W 330 | R1 | 1 |
| 35 | Resistor 0.25W 330 | R7, R8, R10, R11 | 4 |
| 36 | RF Transceiver Module 433MHz 1km | RF | 1 |
| 37 | RFBee 433MHz 1km | RF | 1 |
| 38 | Right Angle Pin Header (Male) | ICSP | 1 |
| 39 | Slide Switch | S1 | 1 |
| 40 | Terminal Block 2 Way | IN | 1 |
| 41 | Terminal Block 2 Way | OUT | 1 |
| 42 | Terminal Block 2 Way | PWR | 1 |
| 43 | Terminal Pin | UART_1 | 3 |
| 44 | Terminal Pin | PWR_1 | 3 |
| 45 | Terminal Pin | UART_2 | 3 |
| 46 | Terminal Pin | UART_2 | 3 |
| 47 | Voltage Regulator 5V TO220 | 7805 | 1 |
| 48 | XBee Starter Kit without module | RF | 1 |
Harga projek RF Fingerprint Attendance and Access System with GSM adalah RM1600 tidak termasuk bantuan teknikal. Di bawah adalah cara projek ini berfungsi.
