VB Project: RF LCD Message
RF LCD Message adalah projek yang memaparkan perkataan di LCD 16X2 yang dihantar daripada software Visual Basic secara wireless melalui RF. Mesej yang diterima disimpan didalam EEPROM supaya RF LCD Message boleh memaparkan mesej yang sama walaupun selepas dimatikan.
Projek yang hampir sama menggunakan paparan Dot Matrix dan DMD.
Skematiknya adalah seperti berikut.
PCB komponen layout nya adalah seperti berikut.
No | Component | Label | Unit |
---|---|---|---|
1 | 073 PCB Arduino Attendance System (83mm X 82mm) | PCB | 1 |
2 | Capacitor SMD1206 0.1uF | C5 | 1 |
3 | Capacitor SMD1206 10uF | C6-C7 | 2 |
4 | Capacitor SMD1206 22pF | C3-C4 | 2 |
5 | Cell Battery CR2032 | Battery 3V | 1 |
6 | Cell Battery Holder | Battery 3V | 1 |
7 | Crystal SMD 16MHz | XTAL1 | 1 |
8 | Crystal SMD RTC 32.768kHz | XTAL2 | 1 |
9 | DC Jack Female | DC Jack Female | 1 |
10 | Diode SMD1206 1N4001 | D1 | 1 |
11 | IC ATMEGA328P-AU TQFP | ATMEGA328 | 1 |
12 | IC DS1307 SOIC | DS1307 | 1 |
13 | LCD 16X2 | LCD | 1 |
14 | PCB Stand (screw nut) | PCB Stand | 6 |
15 | Push Button 4 pin 6x6x1 | PB1-PB4 | 4 |
16 | Resistor SMD1206 0.125W 10K | R4 | 1 |
17 | Resistor SMD1206 0.125W 4.7K | R12 | 1 |
18 | Resistor SMD1206 0.25W 1K | R9-R10 | 2 |
19 | RF Transceiver Module 433MHz 1km | RF | 1 |
20 | RFBee 433MHz 1km | RF | 1 |
21 | Right Angle Pin Header (Male) | ICSP | 1 |
22 | Slide Switch | S1 | 1 |
23 | Terminal Block 2 Way | DC | 1 |
24 | Voltage Regulator 5V TO220 | 7805 | 1 |
25 | XBee Starter Kit without module | RF | 1 |
Harga projek RF LCD Message adalah RM620 dan RF LCD Message with Rechargeable Battery adalah RM910 tidak termasuk bantuan teknikal. Di bawah adalah cara projek ini berfungsi.
